Self-Service Enrollment Flow
This page describes how to build a self-service enrollment flow that supports user-driven provisioning.
Enrollment Flow Design
flowchart LR
P1["Phase 1: Identify the User"]
P2["Phase 2: Verify the User"]
P3["Phase 3: Configure PIN"]
P1 --> P2 --> P3
style P1 fill:#e8f7ee,stroke:#91c7a1,stroke-width:2px
style P2 fill:#fff3dd,stroke:#f0c36d,stroke-width:2px
style P3 fill:#fde5e5,stroke:#ef8c8c,stroke-width:2px
In most deployments:
- Phase 1 uses one or more identifiers to uniquely match the user.
- Phase 2 confirms the matched user before the security key is provisioned.
- Phase 3 is shown only when the applied security key policy requires a PIN.
Self-Service Enrollment Phases
The self-service enrollment process can generally be divided into three phases:
| Phase | Purpose | Available Options / Notes |
|---|---|---|
| Phase 1 - Identify the User | Users provide information so the system can uniquely identify them. | User ID / UPN, Employee ID, Phone Number, First Name + Last Name, Additional Attributes, or a combination of these. The selected combination should uniquely identify a user and should be based on information users commonly know. |
| Phase 2 - Verify the User | After identification, the system verifies that the matched user is correct. | Email verification code, SMS verification code, Automatic verification using Code/API, Self-confirmation, or None. |
| Phase 3 - Configure PIN | Users configure their PIN if required by the security key policy. | PIN setup is controlled by the configured security key policy. If required, users will be prompted to create and confirm their PIN during enrollment. |
Verification Options
Below is a summary of the verification options in Phase 2:
| Verification Option | Description | Example Use Case |
|---|---|---|
| Email Code | Sends a verification code to the user’s registered email address. | Useful when email is a trusted and accessible channel for users. |
| SMS Code | Sends a verification code to the user’s registered phone number. | Useful when mobile phone numbers are available and trusted. |
| Automatic using Code / API | Uses an existing system or association table to verify the user automatically. | For example, if a PACS, badge system, HR system, or internal database already maps users to badge numbers, that data can be validated through API without migrating it into IDmelon. |
| Self-confirmation | Shows the matched user information and asks the user to confirm it is correct. | Useful to prevent mistakes when users enter Employee ID, phone number, or other identifiers. |
| None | Skips the verification step after the user is identified. | Useful when the customer decides identification alone is sufficient for the enrollment flow. |
